Welding Robot Gantry Type Style with Fume Extractor, Ideal for Wire Harness Welding
In automotive, aerospace, and home appliance manufacturing, wire harness welding requires both large-span operational capability and strict environmental protection. The Welding Robot Gantry Type Style with Fume Extractor perfectly meets these demands, integrating the stable and wide-range movement of gantry type style with the environmental protection function of fume extractor to deliver consistent and safe welding results for various wire harnesses.
Gantry Type Style: Stable & Wide-Range for Wire Harness Welding
The gantry type style is the core advantage of the robot in wire harness welding. Its crossbeam and gantry structure enables stable movement across a large working area (up to 2000×1500mm), easily covering long or multi-group wire harness welding tasks. Unlike traditional robotic arms, the gantry structure has higher load-bearing capacity and movement stability, ensuring consistent welding quality even when handling thick-gauge wire harnesses. The X, Y, Z three-axis precise control (positional accuracy ±0.02mm) allows the welding head to accurately align with each welding point of the wire harness, avoiding defects such as false welding or wire breakage. This structure is especially suitable for batch welding of large-scale wire harness assemblies in automotive and industrial equipment.
Fume Extractor: Environmental Protection & Operator Safety
The integrated fume extractor addresses a key pain point in wire harness welding—welding fume pollution. During the welding process, harmful fumes and particles are generated, which pose health risks to operators and pollute the workshop environment. The fume extractor, equipped with a high-efficiency filter, captures fumes at the source through a proximity suction nozzle, filtering out 99% of harmful substances. This not only complies with global industrial environmental protection standards but also creates a safe and healthy working environment for operators. The extractor’s adjustable suction power adapts to different welding intensities, ensuring efficient fume removal without affecting the welding process.
| Product name | Applicable industries |
| robotic soldering machine | Electro-Acoustic |
Wire Harness-Focused Design: Enhancing Production Efficiency
The robot is optimized for wire harness welding workflows. It supports multiple welding modes (spot welding, seam welding) to adapt to different wire harness connection types (terminal welding, wire-to-wire welding). The intuitive control system allows operators to program welding paths easily and store parameters for 50+ wire harness models, enabling quick changeovers between production tasks. Equipped with anti-collision sensors, it automatically stops operation when encountering obstacles, protecting the wire harness and equipment from damage. Its modular design facilitates maintenance and upgrades, ensuring long-term stable operation in high-volume production lines.
In summary, the combination of gantry type style stability, fume extractor environmental protection, and wire harness-focused design makes this robot indispensable for wire harness welding. It delivers the efficiency, quality, and safety required to meet the strict standards of modern manufacturing industries.
